3525 Dip IC SG3525 DIP16 [ 10 Pieces Pack ]

Supply Voltage: 8V to 35V Oscillation Range: 100 Hz to 400 kHz Maximum Power Dissipation: 1000 mW 5.1 V Reference Trimmed TO ± 1 % Supply Voltage VCC: 40 Vdc Logic input: -0.3 to 5.5 V Output current IO: ±500 mA Reference output current Iref: 50 mA Oscillator charging current: 5 mA Power Dissipation PD: 1000 mW Thermal resistance, junction-to-Air RθJA: 100 ˚C/W Thermal resistance, junction-to-Case RθJC: 60 ˚C/W Operating junction temperature TJ: 150 ˚C Dual-source/sink output drivers Internal Soft-Start Pulse by pulse Shutdown Adjustable dead time control Separate oscillator sync terminal Latching PWM to prevent multiple pulses
